Name: TP-Link Switch ES206GP 4XGB POE+ 2XGB 65W Desktop
Brand: TP-LINK
SKU: IRS01689
Availability: InStock

The TP-Link Switch ES206GP is a high-performance network device that offers an ideal solution for small and medium-sized businesses looking to improve their network infrastructure. With 4 Gigabit PoE+ ports and 2 additional Gigabit ports, this switch provides fast and efficient connectivity for a variety of devices, including security cameras, access points and VoIP phones.

This model stands out for its advanced features that ensure optimal operation:

Power over Ethernet (PoE+): Facilitates the installation of devices that require electrical power and reduces the need for cables
65W capacity: Allows you to connect multiple PoE devices without compromising performance.
Gigabit connections: Ensures fast and stable data transfer speeds, improving the user experience in critical applications.
Compact design: Its size allows easy installation in desktops or network closets, optimizing space.

This switch is ideal for environments where efficiency and reliability are essential. It is perfect for companies that need to expand their network without the complexity of complicated installations. With the TP-Link Switch ES206GP, you will enjoy a more robust and efficient network.

Specifications

Brand	TP-Link
Model	ES206GP
Interface	– 6 x RJ45 ports of 10/100/1000 Mbps (ports 1 to 4 support PoE 802.3af and PoE+ 802.3at) – Auto-negotiation/Automatic MDI/MDIX
Hardware	– Fanless – Installation: Desktop and wall mount – Security lock – Power supply: DC power adapter (Output: 53.5 V DC / 1.31 A) – PoE ports (RJ45): Standard: Compatible with PoE 802.3af and PoE+ 802.3at PoE ports: 4 ports Available PoE power: 65 W for all PoE+ ports, 30 W maximum per port Fast PoE and permanent PoE Automatic PoE recovery‡ Up to 250 m PoE transmission distance The speed of the ports that support 250 m PoE transmission will be reduced to 10 Mbps. The actual transmission distance may vary depending on cable quality. – Surge protection: ±6 kV
Software	Quality of Service – Port-based QoS/802.1p/DSCP – 8 Priority Queues – Priority scheduling mode: WRR (Weighted Round Robin) – Queue Weight Config – Bandwidth control: Port-based classification limit – Storm Control: Multiple control modes (kbps/pps) Broadcast/multicast/unknown unicast control L2 Features – Static link aggregation – Loop prevention / Reverse loop detection – Flow control: 802.3x flow control – Mirroring: Port mirroring One to one Many to one Ingress/Egress/Both – Port statistics: Port mirroring status Traffic statistics – 802.1ab LLDP L2 Multicast – IGMP Snooping: IGMP v1/v2/v3 Snooping Fast leave VLAN – VLAN with MTU – Port-based VLAN – 802.1Q tagged VLAN: Maximum 32 VLAN groups 4K VIDEO Transmission Method – Store-And-Forward
Management	– Omada Application * Requires the use of the Omada hardware controller, the Omada cloud-based controller, or the Omada software controller. – Centralized management: Omada cloud-based controller Omada hardware controller Omada software controller – Cloud access * Requires the use of the Omada hardware controller, the Omada cloud-based controller, or the Omada software controller. – Contactless provisioning * Requires the use of the Omada cloud-based controller. – Management features: Web graphical user interface DHCP client Cable diagnostics Automatic device detection Batch configuration Batch firmware upgrade Unified configuration
Other features	– Certification: CE, FCC, RoHS Performance – Switching capacity: 12 Gbps – Packet forwarding rate: 7.44 Mpps – MAC address table: 8k – Packet Buffer Memory: 4 Mbit – Jumbo Frame: 15 KB Environmental Factors – Operating temperature: -5°C-40°C – Storage temperature: -40°C-70°C – Operating humidity: 10%~90% non-condensing – Storage humidity: 5-90% RH non-condensing Dimensions – 294 × 180 × 44 mm Contents – ES206GP – Power adapter – Power cable – Rubber feet – Installation guide
Review date	07-05-2025 by RTY
