VIGI SP6020 Intelligent Solar Power Supply System

Discover the VIGI SP6020 Intelligent Solar Power Supply System from TP-LINK, an innovative solution for your surveillance needs. This intelligent solar power system is designed to provide sustainable and reliable energy to your security devices.

• Ideal for remote locations without access to electricity.
• Easy installation and maintenance.
• Compatible with various surveillance devices.
• Contributes to a more ecological environment by using solar energy.

Technical Specifications

• 60W Photovoltaic Panel and 20.8Ah/10.8V Lithium Battery
• 3 × DC voltage output ports
• Modular design
• Adjustable angles of 5°/15°/25°/35°/45°/55°
• Intelligent auxiliary heating technology
• Charge controller with maximum power point tracking (MPPT)
• IP66 weather resistant
• Remote management and easy installation
• Brand VIGI
• Model VIGI SP6020
• Solar Panel (Photovoltaic Panel) – Power: 60 W
• Voltage: 18 V
• Dimensions (L x W x H): 690 × 516 × 30 mm
• Battery – Type: Lithium
• Intelligent auxiliary heating: Yes
• Battery Capacity: 20.8 Ah
• Voltage: 10.8 V
• Max. Output Voltage: 12.6 V
• Life: Over 500 cycles
• Dimension: 242 × 70 × 55 mm
• Charging Conditions:
• 0°C~45°C
• 30°C~45°C (With intelligent auxiliary heating)
• Discharging Conditions:
• 20°C~60°C
• 30°C~60°C (With intelligent auxiliary heating)
• Angle adjustment (manual) – Range: 5°/15°/25°/35°/45°/55°
• Hardware – Interface
• 1× 10/100 Mbps RJ45
• 1× Photovoltaic Panel Connector
• 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A)
• LED Indicator
• Quantity: 4 (1× SYS indicator, 1× LAN indicator, 1× PV indicator, 1× BAT indicator)
• Color: Blue
• Software Features – Charge control
• Protection against high and low temperatures
• Over-discharge protection
• Energy consumption statistics
• Displays charging status in real time
• Battery level visualization:
• Time zone selection
• Region selection
• Schedule save
• Remote firmware update
• Remote reset
• Local LAN management
• Intelligent charge control: -30°C~5°C
• Account management
• Web management
• Remote reset
• Remote message sending
• Others – Certification
• CB, PSE (Battery)
• CE, FCC, VCCI, IC, IP66
• Package Contents
• VIGI SP6020
• Quick Start Guide
• Waterproof cable accessories
• Weight
• Product weight: 13 kg
• Package weight: 14.5 kg
• Environment
• Operating temperature: -30°C-60°C (With intelligent auxiliary heating)
• Operating humidity: 10%~90%RH, no condensation
