VIGI IP Bullet Camera C345 4MP Metal Full-Color 6m

Discover the VIGI Cámara IP Bullet C345 from TP-LINK, an advanced surveillance solution with Full-Color technology for sharp images even in low-light conditions. With a resolution of 4MP, this camera offers exceptional details and a viewing range of up to 6 meters.

• 4MP resolution: Captures clear and detailed images.
• Full-Color night vision: Color images even in darkness.
• Resistant metal construction: Designed to withstand adverse weather conditions.
• Easy installation: Simple setup for quick and effective surveillance.

Technical Specifications

• Brand VIGI
• Model VIGI C345(6mm)
• Camera – Image Sensor: 1/2.7” Progressive Scan CMOS
• Shutter Speed: 1/3 to 1/10000 s
• Slow Shutter
• Minimum Illumination: 0.005 Lux; 0 Lux with IR/White light
• Day/Night Mechanism: IR Cut Filter
• Day/Night Switch: Day/Night/Auto/Scheduling
• Lens – Type: Fixed focal lens
• Focal Length: 6 mm
• Aperture: F1.6
• FOV:
• Horizontal FOV: 52.7°
• Vertical FOV: 29°
• Diagonal FOV: 60.8°
• Lens Mount: M12
• DORI Distance
• Detection: 120m
• Observation: 50 m
• Recognition: 24 m
• Identification: 12 m
• Illumination
• Number of IR LEDs: 2
• Range: 30m
• Wavelength: 850 nm
• Number of Infrared LEDs: 2
• Range: 30m
• Lighting Control On/Off: Automatic/Scheduled/Always On/Always Off
• Image and Video Image
• Image Settings:
• Mirror
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR
• White Balance
• HLC adjustable via client software
• Image Enhancement: BLC/3D DNR/HLC/SmartIR
• Wide Dynamic Range: 120 dB
• Note: When People & Vehicle Analytics is enabled, only DWDR is supported.
• SNR: ≥ 52dB
• Image Parameter Switch
• Privacy Mask: up to 4 masks
• ROI: 1 Region
• OSD Settings
• Video
• Max. Resolution: 2688 x 1520
• Main Stream Frame Rate:
• 50 Hz: 1 fps, 5 fps, 10 fps, 15 fps, 20 fps, 25 fps
• 60 Hz: 1 fps, 5 fps, 10 fps, 15 fps, 20 fps, 25 fps, 30 fps
• Main Stream Resolution:
• 2688×1520
• 2560×1440
• 2304×1296
• 2048×1280
• 1920×1080
• 1280×720
• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20 fps.
• Sub-Stream Frame Rate:
• 50 Hz: 1 fps, 5 fps, 10 fps, 15 fps, 20 fps, 25 fps
• 60 Hz: 1 fps, 5 fps, 10 fps, 15 fps, 20 fps, 25 fps, 30 fps
• Sub-Stream Resolution: 640×480, 352×288, 320×240
• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20 fps.
• Bit Rate Control: CBR, VBR
• Video Compression:
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
• H.264 Type: Main Profile/High Profile
• H.264+: Supported Main Stream
• H.265 Type: Main Profile
• H.265+: Supported Main Stream
• Main Stream Video Bit Rate: 256 Kbps to 4 Mbps
• Sub-Stream Video Bit Rate: 64 Kbps to 512 Kbps
• Interfaces – 1 x Self-adaptive RJ45 10/100M Ethernet port, PoE
• Reset Button
• Power: DC Power Port
• Built-in Storage: Integrated memory card slot, compatible with MicroSD card, up to 512 GB
• Built-in Microphone: Records everything happening within a 15-foot radius of the camera
• Built-in Speaker
• Features Network
• Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
• ONVIF
• API: ONVIF
• Simultaneous Live View: 3 Main Streams and 3 Sub Streams
• Client: VIGI App, VIGI Security Manager, VIGI NVR, Web
• Web Browser:
• Google Chrome 57 and above
• Firefox 52 and above
• Safari 11 and above
• Microsoft Edge 91 and above
• Cloud
• Security: Password Protection, HTTPS Encryption, IP Address Filtering, Digest Authentication
• Network Storage: NAS (NFS, SMB/CIFS)
• Alarm
• Intelligent Classification of People and Vehicle Events
• Area Intrusion Detection
• Line Crossing Detection
• People Detection
• Vehicle Detection
• Region Entry Detection
• Region Exit Detection
• Abandoned Object Detection
• Object Removal Detection
• Basic Detection:
• Motion Detection
• Video Tampering Detection
• Exception (Illegal Login)
• Alarm Link: Push Message
• Output Notification: Push Message
• Power
• Power Supply:
• 12V DC ± 5%, Max. 9.7 W
• 5.5 mm Coaxial Power Plug
• PoE: 802.3af/at, class 0, max. 10.7W
• Dimensions and Weight
• 184 × 74 × 74 mm
• 0.525 kg
• Contains
• VIGI Network Camera
• Quick Start Guide
• Waterproof Cable Accessories
• Mounting Accessories
