Name: TP-LINK EAP225-Outdoor Access Point AC1200 PoE
Brand: TP-LINK
SKU: IRS01951
Availability: InStock

The TP-Link EAP225-Outdoor is an access point designed to provide a robust and reliable Wi-Fi connection on exterior, ideal for companies, parks, campus, and any environment where network coverage is essential. With a dual speed of up to 1200 Mbps, this device offers exceptional performance, allowing users to enjoy streaming, videoconferences and navigation without interruptions.nnEquipped with Poe technology (Power over Ethernet), the EAP225-Outdoor simplifies the installation, since it can receive food and data through a single Ethernet cable. This means that you do not need an additional current adapter, which facilitates its placement in difficult places. Its weather -resistant design, with IP65 classification, guarantees that the device works without problems in various climatic conditions, either under rain or exposed to high temperatures.nnThe EAP225-Outdoor also has advanced network management functions, which allows administrators to configure and monitor multiple access points from one place. Thanks to its compatibility with the SDN OMADA platform, it can be managed centrally, optimizing network performance and improving user experience.nnIn addition, its ability to handle multiple devices simultaneously makes it an ideal option for environments with high user density. With advanced safety characteristics, such as WPA/WPA2, the network remains protected against unauthorized accesses. In short, the TP-Link EAP225-Outdoor is the perfect solution for those who seek a powerful and reliable Wi-Fi connection on exterior.

Specifications

Brand	TP-Link
Model	EAP225-Outdoor
Features	Hardware – Interface: Gigabit Ethernet port (RJ-45) * 1 (supports 802.3af PoE and passive PoE) – Button: Reset – Power Supply: 802.3af PoE and 24V passive PoE (PoE adapter included) – Power Consumption: 10.5W – Antenna: 2.4GHz: 2 * 3dBi, 5GHz: 2 * 4dBi – Dimensions (W x D x H): 8.5 × 1.8 × 1.1in. (215 × 46 × 27 mm) – Mounting: Pole / Wall Mount (Kits included) – Watch Dog: Yes Wireless – Wireless Standards: IEEE 802.11a / b / g / n / ac – Frequency: 2.4GHz, 5GHz – Signal Rate: 802.11ac: 5G: 6.5 Mbps to 867Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20 / 40/80) 2.4G: 78Mbps to 300Mbps (MCS8-MCS9 VHT20 / 40, NSS = 1 to 3) 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40) 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 5.5, 11Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps – Wireless Functions: Multiple SSIDs (up to 16 SSIDs, 8 for each band) Enable / disable wireless radio Automatic channel assignment Transmit power control (adjust transmission power in dBm) QoS (WMM) MU-MIMO Airtime fairness Beamforming Band steering Load balancing Ratio limit Reboot schedule Wireless schedule Wireless statistics based on SSID / AP / Client – Wireless Security: captive portal authentication Access control Wireless MAC Address Filtering Wireless client isolation SSID to VLAN assignment Rogue AP detection 802.1X compatibility – Transmission Power: CE: <20dBm (2.4GHz, EIRP), <23dBm (5GHz, EIRP) FCC: <30dBm (2.4GHz, EIRP), <30dBm (5GHz, EIRP)
Management	– Omada controller software: yes – Email alerts: yes – MAC management access control: Yes – Local / Remote Syslog system logging: Yes – Web-based management: yes – L3 management: Yes – Multi-site management: yes – Management VLAN: yes
Others	– Certification: CE, FCC, RoHS – Environment: Operating temperature: -30ºC ~ 70ºC – Storage temperature: -40ºC ~ 70ºC – Operating humidity: 10% ~ 90% non-condensing – Storage humidity: 5% ~ 90% non-condensing Contents – AC1200 Wireless MU-MIMO Gigabit Indoor / Outdoor Access Point – EAP225-Outdoor – Power adapter – Mounting kits – Installation guide
Review Date	17-04-2018 by MSB
