Name: TP-LINK EAP225 Access Point AC1350 Dual Band PoE
Brand: TP-LINK
SKU: IRS01930
Availability: OutOfStock

The TP-Link EAP225 is a high-performance access point designed to offer reliable and fast wireless connectivity in commercial and residential environments. With its double band technology, this device can reach speeds of up to 1350 Mbps, allowing multiple users to connect simultaneously without loss of signal quality.nnThis model stands out for its ability to operate in 2.4 GHz and 5 GHz bands, which means you can enjoy a more agile and less congested network. Ideal for large spaces, EAP225 is perfect for offices, restaurants, or anywhere where extensive and constant coverage is required. In addition, its elegant and discreet design allows you to integrate perfectly into any decoration.nnOne of the most prominent features of the EAP225 is its support for Power Over Ethernet (POE), which simplifies the installation by allowing the device to receive energy and data through the same Ethernet cable. This means that you can locate the access point in places where there are no near power shots, facilitating its placement on ceilings or walls.nnIn addition, the EAP225 has a centralized management system through the TP-Link controller, which allows you to manage and monitor your network in a simple and efficient way. With advanced functions such as access control, bandwidth management and the possibility of creating multiple SSID, this access point is the ideal solution for those who seek to improve their connectivity and optimize their wireless network. With the TP-Link EAP225, you will enjoy a fluid navigation experience without interruptions.

Specifications

Gigabit Wireless MU-MIMO AC1350 Ceiling Mount Access Point EAP225

– Wi-Fi speeds of up to 1350Mbps in total, with 450Mbps on 2.4GHz and 867Mbps on 5GHz
– Free EAP Controller Software that allows administrators to easily manage hundreds of EAPs
– Supports Power over Ethernet (802.3af) and Passive PoE for practical and flexible installation
– Captive Portal that provides a practical method for guest authentication
– The Band Steering function automatically shifts dual-band devices to the wider 5GHz band for faster connections
– MU-MIMO means that one access point transfers data simultaneously with multiple devices, increasing connection speeds.
– Beamforming concentrates the signal where it is most needed, providing a fast and stable Wi-Fi experience.
– Schedules can be defined on the access points for them to automatically reboot and/or disable/enable the WiFi signal within a desired timeframe.

Brand	TP-LINK
Model	EAP225
Features	HARDWARE – 1 x Gigabit Ethernet Port (RJ-45)(Supports IEEE802.3af PoE and Passive PoE) – Reset Button – Power Supply: 802.3af/A PoE Passive PoE 24V (+4,5pins; -7,8pins. PoE Adapter Included) – Power Consumption: EU: 10.5W / US: 12.6W – Dimensions: 205.5 × 181.5 × 37.1 mm. (8.1 × 7.1 × 1.5 in) – Antenna Type: 3 Omnidirectional Antennas 2.4GHz: 4dBi 5GHz: 5dB – Mounting: Ceiling/Wall Mount (Kits included) – Physical Security Lock: Yes – Hardware Watch Dog: Yes WIRELESS – Wireless Standards: IEEE 802.11ac/n/g/b/a – Frequency: 2.4GHz and 5GHz – Signal Rate: 5GHz: Up to 867Mbps 2.4GHz: Up to 450Mbps* – Wireless Functions: Multiple SSIDs (Up to 16 SSIDs, 8 per band) On/Off Wireless Radio Automatic Channel Assignment Transmission Power Control (Adjustment by dBm) QoS (WMM) Band Steering Load Balancing MU-MIMO * Airtime Fairness * Beamforming * Speed Limit Scheduled Reboot Scheduled Wireless Wi-Fi Statistics based on SSID/AP/Client – Wireless Security: Captive Portal Authentication Access Control Wireless MAC Address Filtering Wireless Client Isolation VLAN Mapping by SSID Rogue AP Detection 802.1X Support – Transmission Power: CE: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <24dBm(2.4GHz) <22dBm(5GHz) Management – EAP Controller Software: Yes – Email Alerts: Yes – LED Control ON / OFF: Yes – MAC Access Control Management: Yes – SNMP: v1,v2c – Access to Local System Log/ Remote System Log: Local/Remote Syslog – Telnet: Yes – Web-based Management: HTTP/HTTPS – L3 Management: Yes – Multi-site Management: Yes – Management VLAN: Yes Others – Certifications: CE, FCC, RoHS – System Requirements: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Linux – Environmental Factors: Operating Temperature: 0?~40? (32?~104?) Storage Temperature: -40?~70? (-40?~158?) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing Contents – AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point – Passive PoE Adapter – Power Cable – Mounting Kit – Installation Guide
Review Date	25-09-2018 by MSB
