TP-Link DS-P7001-04 OLT GPON 1x10Gb SFP+ 4xPON
1 189,37 €
The TP-Link DS-P7001-04 OLT GPON offers high speed with a 10GB SFP+ Port port and four PON ports, ideal for high performance optical networks and reliable connectivity.
Shipping Cost & Delivery Time
The TP-Link DS-P7001-04 OLT GPON is a high-capacity network solution designed for telecommunications operators that seek to offer last generation fiber optic services. This equipment has a 10GB SFP+ port, allowing rapid and efficient connectivity, ideal to meet the growing bandwidth demands in urban and rural environments.nnWith four PON ports, the DS-P7001-04 offers the possibility of connecting multiple end users, guaranteeing exceptional performance and an optimal signal distribution. Its compact and robust design allows easy installation in various network configurations, adapting to the specific needs of each operator.nnThis OLT GPON of TP-Link is compatible with ITU-T G.984 standards, which ensures interoperability with other network devices and equipment. In addition, its advanced management allows monitoring and managing the network efficiently, facilitating problems detection and performance optimization.nnThe DS-P7001-04 also includes advanced safety features, protecting the integrity of the data and guaranteeing safe communication between the end users and the service provider. With a scalability -oriented design, this OLT is a long -term investment that supports network growth and services expansion.nnIn summary, the TP-Link DS-P7001-04 OLT GPON 1x10GB SFP+ 4xpon is the ideal solution for operators seeking reliability, performance and flexibility in their fiber optic networks.
Specifications
| Brand | TP-Link |
| Model | DS-P7001-04 |
| Hardware | – Interface 1 SFP+ 10 Gbps uplink port, 1 RJ45 10/100/1000 Mbps uplink port, 4 PON ports (SFP slot), 1 RJ45 console port, 1 RJ45 MGMT port, 1 alarm port – Button: reset button – Power supply: Dual power supply, AC: 100 V~240 V, 50/60 Hz, DC: -38.4 V~-72 V – Dimensions (W x D x H): 440 x 180 x 44 mm (17.3 x 7.1 x 1.7 inches) – Power consumption: Max. 58W – Max. Split ratio: 1:128 – Data rate: Downstream: 2.5 Gbps; Upstream: 1.25 Gbps – Wavelength: Tx: 1490nm, Rx: 1310nm – Fiber type: 9/125 μm SMF (single-mode fiber) – Transmission distance: 20 km – Interface type: SC/UPC – Tx power: Class C+ |
| Software | Basic Functions – OMCI: Standard OMCI management supported – ONU Authentication: Automatic ONU authentication – Multi-service: Multi-service traffic identification and speed limit – Routing: Static routing – Multicast: IGMP Snooping/MLD Snooping – DHCP: DHCP server and DHCP relay |
| Management | Security – Security ACL 802.1x authentication ARP inspection IP source protection – ONU Security: Rogue ONU detection and isolation Uplink and downlink data encryption – Quality of service: QoS IEEE 802.1p/DSCP Voice VLAN Automatic VoIP Centralized Management – Large-scale device management – Batch OLT configuration, update, reboot – Multiple site management – Intelligent network monitoring – Real-time network overview |
| Certifications – Certifications: CE, FCC Environmental Features – Operating temperature: 0°C~50°C (32°F~122°F) – Storage temperature: -40°C~70°C (-40°F ~158°F) Contents – OLT device – Power cable and console cable – Installation guide – Mounting brackets, screws, and rubber feet |
|
| Review Date | 26-10-2022 by MPM |
Additional information
| Weight | 3,6 kg |
|---|---|
| Dimensions | 44,0 × 18,0 × 4,0 cm |
