TP-LINK CPE510 N300 PoE Access Point
Roll over image to zoom in
55,41 €
The TP-Link CPE510 is a N300 access point with POE technology, ideal for extending outdoor wireless networks, offering long-range stable and long-range connectivity for your devices.
Shipping Cost & Delivery Time
The TP-Link CPE510 is an access point designed to offer a high-performance wireless connectivity solution, ideal to cover extensive areas in exterior environments. With a speed of up to 300 Mbps, this device operates in the 2.4 GHz band, guaranteeing an efficient and stable data transmission, perfect for applications that require a continuous and quality connection.nnEquipped with a 13 dBI directional antenna, the CPE510 allows to reach distances of up to 5 km, which makes it the ideal option for long -distance connections, such as in campus, farms or rural areas. Its robust and resistant design to the inclement weather ensures optimal performance even in adverse climatic conditions, which provides tranquility and reliability in connection.nnThe CPE510 also incorporates Poe (Power Over Ethernet) technology, which means that it can be fed through the network cable, simplifying the installation and eliminating the need for an additional power supply. This is especially useful in locations where access to current shots is limited.nnIn addition, its intuitive management interface allows rapid and simple configuration, as well as the personalization of security parameters, ensuring that your network is always protected against unauthorized access. With the TP-Link CPE510, you will get a versatile and reliable connectivity solution, perfect to meet the needs of external networks in various applications.
Specifications
CPE for Outdoors of 13dBi and 5GHz at 300Mbps
– TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance, capacity, and latency, ideal for PTMP applications
– Operating modes: AP / Client / Repeater / AP Router / AP Client Router (WISP)
– Dual-polarized directional MIMO antenna of 13dBi and 2×2
– Adjustable transmission power from 0 to 27 dBm / 500mw
– System-level optimizations for wireless transmission over more than 15 kilometers of range
– TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology enhances the product in performance, capacity, and latency time, ideal for PTMP applications
– Centralized Management System – Pharos Control
– Passive PoE adapter supports a maximum of 60 meters (200 feet) of PoE implementation and allows the device to be reset remotely
– Operating modes: AP / Client / Repeater / AP Router / AP Client Router (WISP)
– Dual-polarized directional MIMO antenna of 13dBi and 2×2
– Adjustable transmission power from 0 to 27 dBm / 500mw
– System-level optimizations for wireless transmission over more than 15 kilometers of range
– TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology enhances the product in performance, capacity, and latency time, ideal for PTMP applications
– Centralized Management System – Pharos Control
– Passive PoE adapter supports a maximum of 60 meters (200 feet) of PoE implementation and allows the device to be reset remotely
What this product is for
TP-LINK’s 5GHz 300Mbps 13dBi Outdoor CPE, the CPE510 is dedicated to cost-effective solutions for outdoor wireless networking applications. With its centralized management application, it is ideal for point-to-point, point-to-multipoint, and outdoor Wi-Fi coverage applications. Professional performance, along with an easy-to-use design, makes the CPE510 an ideal option for both home and business users.
TP-LINK’s 5GHz 300Mbps 13dBi Outdoor CPE, the CPE510 is dedicated to cost-effective solutions for outdoor wireless networking applications. With its centralized management application, it is ideal for point-to-point, point-to-multipoint, and outdoor Wi-Fi coverage applications. Professional performance, along with an easy-to-use design, makes the CPE510 an ideal option for both home and business users.
Enterprise Hardware Design
With Qualcomm Atheros enterprise-grade chipsets, high-gain antennas, high-quality material, specially designed housing, and PoE power supply, the CPE510 is specifically designed for outdoor use and can operate smoothly in almost any weather, with operating temperatures from -30 °C (-22 °F) to 70 °C (158 °F).
With Qualcomm Atheros enterprise-grade chipsets, high-gain antennas, high-quality material, specially designed housing, and PoE power supply, the CPE510 is specifically designed for outdoor use and can operate smoothly in almost any weather, with operating temperatures from -30 °C (-22 °F) to 70 °C (158 °F).
Advanced Antenna System
High-gain antenna, dual polarization, and metal reflection ensure greater gain and lower noise interference.
High-gain antenna, dual polarization, and metal reflection ensure greater gain and lower noise interference.
High Power and Sensitivity
High transmission power Tx (up to 27 dBm / 500mw) and high sensitivity Rx (up to -95 dBm) from front to back radio and a design that breaks the barriers of traditional Wi-Fi transmission range, making the CPE510 an ideal product for outdoor applications for wireless networks.
High transmission power Tx (up to 27 dBm / 500mw) and high sensitivity Rx (up to -95 dBm) from front to back radio and a design that breaks the barriers of traditional Wi-Fi transmission range, making the CPE510 an ideal product for outdoor applications for wireless networks.
Professional Outdoor Design
The CPE510 is designed to work in challenging environments, even in some of the most hostile weather conditions in the world.
The CPE510 is designed to work in challenging environments, even in some of the most hostile weather conditions in the world.
Weather-resistant design
With its weather-resistant housing and industrial-grade design hardware, the CPE510 can continue to operate in various weather conditions, such as sun, rain, wind, snow, or extremely low/high temperatures (-30 °C ~ 70 °C).
With its weather-resistant housing and industrial-grade design hardware, the CPE510 can continue to operate in various weather conditions, such as sun, rain, wind, snow, or extremely low/high temperatures (-30 °C ~ 70 °C).
Double Protection against ESD attacks
In addition to grounding, the CPE510 offers another way to eliminate ESD attacks through the PoE adapter and Ethernet cable with grounding. The additional security measures of the CPE510 provide up to 15KV ESD and lightning protection of up to 6000V for more reliable operation.
In addition to grounding, the CPE510 offers another way to eliminate ESD attacks through the PoE adapter and Ethernet cable with grounding. The additional security measures of the CPE510 provide up to 15KV ESD and lightning protection of up to 6000V for more reliable operation.
TP-LINK MAXtream TDMA Technology
As the network scale increases, the competition and wireless collisions between the CPEs and base stations will be so enormous that the actual network performance will drop, resulting in a severe impact on the end-user experience. To mitigate these effects, the CPE510 uses MAXtream TDMA technology.
As the network scale increases, the competition and wireless collisions between the CPEs and base stations will be so enormous that the actual network performance will drop, resulting in a severe impact on the end-user experience. To mitigate these effects, the CPE510 uses MAXtream TDMA technology.
Wireless Data Transmission over more than 15km
Specifically designed for outdoor applications, ideal for long-distance wireless data transmission of up to 15 kilometers, tested in real-world situations.
Specifically designed for outdoor applications, ideal for long-distance wireless data transmission of up to 15 kilometers, tested in real-world situations.
Pharos Control – Central Management System
The CPE510 also comes equipped with centralized management software that helps users easily manage all devices in their network from a single computer – Pharos Control. Functions such as device detection, status monitoring, firmware updates, and network maintenance can be handled using Pharos Control.
The CPE510 also comes equipped with centralized management software that helps users easily manage all devices in their network from a single computer – Pharos Control. Functions such as device detection, status monitoring, firmware updates, and network maintenance can be handled using Pharos Control.
PharOS
Web-based management system, easy to use, allowing professionals to make more specific configurations.
Web-based management system, easy to use, allowing professionals to make more specific configurations.
| Brand | TP-LINK |
| Model |
CPE510
|
| Features |
– Processor: Qualcomm Atheros Enterprise AR9350B 560MHz CPU, MIPS 74Kc
– Memory: 64MB DDR2 RAM, 8MB Flash – Interfaces: 1 10/100Mbps Shielded Ethernet Port (LAN0, Passive PoE input) 1 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough) (Output 24VDC, 1.0A Max) 1 Grounding Terminal 1 Reset Button – Antenna type: 13dBi 2×2 Dual-Polarized Directional Antenna Directional Antenna Frame profile: 45° (H-Plane) / 30° (E-Plane) Note: For more details, please refer to the datasheet – Protection: 15KV ESD protection – Lightning protection of 6000V – Power consumption: Maximum of 13 Watts Note: When implemented using passive PoE, the power obtained from the power source will vary depending on the length of the connection cable. – Power supply: Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) – Voltage Range: 16-27VDC – Enclosure: Outdoor stabilized ASA plastic material – IPX5 water certification WIRELESS FEATURES – Wireless Standards: IEEE 802.11a/n (with Pharos MAXtream disabled) Proprietary Protocol TDMA Mode (with Pharos MAXtream enabled) Wireless Speeds: Up to 300Mbps (40MHz, Dynamic) Up to 144.4Mbps (20MHz, Dynamic) Up to 72.2Mbps (10MHz, Dynamic) Up to 36.1Mbps (5MHz, Dynamic) – Frequency: 5.15~5.85GHz Note: The available operating frequency may vary depending on the limitations of the countries or regions in which the device is used. – Reception Sensitivity: – 802.11a: 54M: -75dBm, 48M: -76dBm, 36M: -83dBm, 6-24M: -95dBm – 802.11n: MCS15: -73dBm, MCS14: -74dBm, MCS13: -76dBm, MCS12: -80dBm, MCS11: -83dBm, MCS10: -88dBm, MCS9: -90dBm, MCS8: -93dBm, MCS7: -73dBm, MCS6: -74dBm, MCS5: -76dBm, MCS4: -80dBm, MCS3: -83dBm, MCS2: -88dBm, MCS1: -90dBm, MCS0: -93dBm – Transmission Power: 27dBm/500mw (Adjustable Power up to 1dBm) Note: the maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used. SOFTWARE FEATURES – Wireless Configurations: MAXTream TDMA Technology 802.11a/n Modes Selectable channel width: 5/10/20/40MHz Automatic Channel Selection Power transmission control Dynamic Frequency Selection (DFS) WDS Enabled/Disabled Security: WPA/WPA2, WPA-PSK/WPA2-PSK Encryption (AES/TKIP), 64/128/152-bit WEP Encryption SSID Broadcast Enabled/Disabled Multi-SSID with VLAN tagging (only in AP mode) Distance and ACK Time End settings Wireless MAC address filtering Advanced wireless options: > Beacon Interval/RTS Threshold/Fragmentation >Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia – Management: Discovery and remote management through Pharos control applications Web-based HTTP/HTTPS Management System Log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server – System Tools: Wireless signal quality indicators: Signal strength / noise / Transmit CCQ / CPU / Memory Monitors: Throughput / Stations / Interfaces / ARP / Routes / WAN / DHCP Spectrum Analyzer Speed Test Ping Traceroute – System-level Optimizations: IGMP Snooping / Proxy optimized for multicast applications Hardware watch dog |
| Other Features |
– Certifications: CE, FCC, RoHS, IPX5
– Package Contents: Outdoor wireless CPE 24V 1A passive PoE adapter Mounting straps AC power cable Installation guide – System requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. Note: We recommend using one of the following web browsers for an enhanced user experience: Google Chrome, Safari, and Firefox. Internet Explorer is not recommended. – Environmental factors: Operating Temperature: -30°C~70°C (-22°F~158°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing POE ADAPTER FEATURES – Button: Remote reset button – Certifications: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark – Dimensions(W x D x H): 110*57*33.5mm – Efficiency: >80% – Input: 100-240VAC, 50/60Hz – Input Current: 0.8A Max @ 100VAC – Input Voltage: 100VA~240VAC @ 50Hz~60Hz – Power Status LEDs: Green: 0~0.8A Red: 0.8A~1.0A – Dimensions (W X D X H): 224 x 79 x 60 mm |
| Revision Date | 11-09-2014 by FE4 |
Additional information
| Weight | 0,875 kg |
|---|---|
| Dimensions | 13,0 × 11,0 × 27,0 cm |
