SYNOLOGY RS1619xs+ NAS 4Bay Rack Station

The Synology RS1619XS+ is a powerful 4 -bay NAS station designed to meet the needs for storage and data management of companies of all sizes. With a Rack design, this solution offers exceptional performance and impressive scalability, ideal for work environments that require rapid and safe access to large volumes of information.

Equipped with a multi -nuclei processor and expandable RAM, the RS1619XS+ guarantees a fast data transfer speed, which facilitates real -time collaboration between equipment. Its ability to manage multiple tasks simultaneously allows a fluid experience, even under intensive workloads. In addition, it has virtualization technology, which makes it an excellent option for companies that seek to implement private cloud solutions.

The installation and configuration of the RS1619xS+ is simple thanks to its intuitive user interface. With support for various Synology applications, such as file management, backup copies and multimedia solutions, this NAS adapts to the specific needs of each business. Data safety is a priority, and RS1619xS+ offers multiple layers of protection, including data encryption and disaster recovery options.

With the possibility of expanding storage capacity through additional units and connection to other devices, Synology RS1619xS+ becomes a long -term investment. In short, it is the perfect solution for those companies that seek a reliable, efficient and easy to manage storage system.

Technical Specifications

• Synology Brand
• Model RS1619xs+
• CPU – Intel Xeon D-1527
• CPU Architecture: 64-bit
• Quad-core 2.2 GHz (base) / 2.7 (turbo) GHz
• Hardware Encryption Engine (AES-NI)
• Memory
• System Memory: 8GB DDR4 ECC UDIMM
• Pre-installed Memory Module: 8GB (1 x 8GB)
• Total Memory Slots: 4
• Expandable Memory up to: 64GB (16GB x 4)
• Storage
• Drive Bays: 4
• Max. Drive Bays with Expansion Unit: 16
• Drive Type
• 3.5″ SATA HDD
• 2.5″ SATA HDD
• 2.5″ SATA SSD
• M.2 2280 NVMe & SATA SSD
• Maximum Internal Capacity: 56 TB (14TB hard drive x 4)
• Maximum Raw Capacity with Expansion Units: 224TB (56TB + 14TB drive x 12) (Capacity may vary depending on RAID type)
• Maximum Single Volume Size:
• 200 TB (requires 32GB RAM, only for RAID 5 or RAID 6 groups)
• 108TB
• Hot Swappable Drive
• Compatible RAID Type: RAID F1, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
• Connections – 4 x RJ-45 1GbE LAN (with Failover / Link Aggregation support)
• 2 x USB 3.0
• 1 x Expansion Port
• Features
• File System
• Internal Drives: Btrfs, EXT4
• External Drives: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT
• Appearance
• Size (Height X Width X Depth): 44 x 480 x 518.6 mm
• Weight: 8.16 kg
• Certification
• FCC
• CE
• BSMI
• EAC
• VCCI
• CCC
• RCM
• KC
• Network Protocols
• CalDAV
• iSCSI
• Telnet
• SSH
• SNMP
• VPN (PPTP, OpenVPN, L2TP)
• Others
• System Fan: 40 mm x 40 mm x 2 pcs
• Power Recovery
• Noise Level: 39.3 dB dB(A)
• Scheduled On/Off
• Wake on LAN/WAN
• Power Supply / Adapter: 2 x 150W (redundant)
• Input Power Voltage: 100V to 240V AC
• Power Frequency: 50/60 Hz, Single Phase
• Power Consumption: 68.68 W (Access)
• 34.78 W (Hard Drive Hibernation)
• Revision Date 12-04-2019 by MSB
