Name: Salicru SLC 30 CUBE 3+
Brand: Salicru
SKU: IEN00471
Availability: OutOfStock

Discover the Salicru SLC 30 CUBE 3+, a high-efficiency uninterruptible power supply (UPS) designed to protect your most valuable electronic devices. This model is ideal for domestic and professional environments, guaranteeing the continuity of the electrical supply and the safety of your equipment against power outages and voltage spikes.

Among its main benefits, the SLC 30 CUBE 3+ stands out for:

3000 VA capacity: Provides powerful autonomy to keep your equipment running without interruptions.
Automatic voltage regulation (AVR): It maintains a constant and stable supply, protecting your devices from dangerous fluctuations.
Compact design: Its modern and functional design allows easy integration into any space without taking up much space.
USB connectivity: Allows management and monitoring of the UPS from your computer, facilitating its use and configuration.

This UPS is perfect for protecting computers, servers, network equipment and other sensitive devices. Don’t leave the security of your technology to chance, choose the Salicru SLC 30 CUBE 3+ and make sure your equipment is always safe from electrical interruptions.

Specifications

Brand	Salicru
Model	681LB000006
Type	– Tower
Technology	– On-line, double conversion, HF, DSP control
Input	– Voltage: 220 / 230 / 240 V – 3 x 380 / 3 x 400 / 3 x 415 V (3F + N) – Voltage range: +15% / -20% (configurable) – Nominal frequency: 50 / 60 Hz – Total Harmonic Distortion (THDi): 100% load: <1.0% / 50% load: <2.0% / 10% load: <5.0% – Power factor: 1 from 10% load – Rectifier topology: Three-phase IGBT full wave, soft start and PFC, transformerless
Output	– Power factor: 0.9 – Voltage: 220 / 230 / 240 V – 3 x 380 / 3 x 400 / 3 x 415 V (3F + N) – Dynamic accuracy: ±2% dynamic – Static accuracy: ±1% static – Response time accuracy: 20 ms for load jumps 0%÷100% and voltage drop up to -5% – Power (VA/W): 30000 / 27000 – Total Harmonic Distortion (THDv) linear load: <0.5% – Total Harmonic Distortion (THDv) non-linear load: <1.5% (EN-62040-3) – Synchronized frequency: 50/60 Hz ±5 Hz (selectable) – Frequency accuracy (battery mode): 50/60 Hz ±0.05% – Synchronization speed: From 1 Hz/s to 10 Hz/s (programmable) – Eco-mode efficiency: 97.4% – Total efficiency in On-line mode: 7.5÷60 kVA: 92.0%÷93.0% / 80÷200 kVA: 94.0%÷95.0% – Acceptable overload: 125% for 10 min / 150% for 60 s / >150% for 20ms – Crest factor: 3.2 to 1 Bypass – Manual bypass: No interruption – Type and activation criteria: Solid state – Smart Eco-mode transfer time (ms): 4 ms (typical) – On-line mode transfer time: None – Transfer to bypass: Immediate, for overloads above 150% – Re-transfer: Automatic, after alarm disappearance
Battery	– Battery type: Lead acid, sealed, maintenance-free – Charge voltage regulation: Batt-Watch
Communication	– Ports: 1x RS232/RS485 + 1xUSB, with Modbus protocol – Relay interface: 4 x AC failure, bypass, low battery and general – Smart slot: 1, for SNMP – Monitoring software: Viewpower / UPSMAN – LCD display: LCD display, LEDs and keyboard
General	– Operating temperature: 0º C ÷ +40º C – Relative humidity: Up to 95%, non-condensing – Maximum operating altitude: 2,400 m.a.s.l. – Acoustic noise at 1 meter: <52 dB(A) Systems – Max number of systems in parallel: Yes, up to 4 units. Ring connection. Frequency converters (FC) are parallelable. Configurations – Number of cabinets (UPS + BAT): 1 + 0
Regulations	– Safety: EN-IEC 62040-1 – Electromagnetic compatibility (EMC): EN-62040-2 – Operation: VFI-SS-11 (EN-62040-3) – Quality and Environmental Management: ISO 9001 & ISO 14001
Dimensions	– Depth (mm): 770 – Width (mm): 450 – Height (mm): 1100 – Weight (kg): 305
Review date	17-11-2022 by MPM
