QNAP TS-855X-8G NAS 6+2 Bay 2×2.5GbE 4xUSB

The QNAP TS-855x-8G is an advanced NAS (Network Attached Storage) designed to meet the data of data storage and management both in domestic and business environments. With a capacity of 6+2 bays, this device allows great flexibility in the configuration of discs, offering ample space to store and share files efficiently. Its robust and elegant design adapts perfectly to any office or living room.

Equipped with a four-core Intel Celeron processor and 8 GB of RAM, the TS-855x-8G provides exceptional performance, ideal for tasks such as the transmission of media, security and virtualization copies. In addition, it includes two 2.5GBE ports that allow rapid and efficient data transfer, improving connectivity and speed access speed. With four USB ports, you can easily connect external devices for greater expansion and data backup.

Data management in QNAP TS-855x-8G is intuitive thanks to its QTS operating system, which offers an easy-to-use interface and numerous applications to optimize productivity. From the synchronization of cloud files to the creation of multimedia servers, this NAS adapts to different needs, always guaranteeing the safety and integrity of your data.

Whether for personal or professional use, the Qnap TS-855x-8G is a versatile and powerful storage solution, which combines performance, capacity and ease of use in a single device. With him, you can enjoy the tranquility of having your data always accessible and protected.

Technical Specifications

• Brand QNAP
• Model TS-855X-8G
• CPU – CPU: Intel Atom C5125 8-core processor, 2.8GHz
• CPU Architecture: x86 64-bit
• Floating Point Unit
• Encryption Engine: (AES-NI)
• Hardware-accelerated Transcoding
• Memory – System Memory: 8 GB non-ECC UDIMM DDR4 (1 x 8 GB)
• Maximum Memory: 128 GB (4 x 32 GB modules)
• 4 x DDR4 UDIMM memory modules
• ECC Memory Support
• Storage – Flash Memory: 5GB (dual-boot operating system protection)
• Drive Bays: 6 x 3.5″ SATA drives + 2 x 2.5″ SATA drives at 6 Gb/s, 3 Gb/s
• * The system is shipped without a hard drive
• * To view the hard drive compatibility list, visit https://www.qnap.com/compatibility/
• Drive Compatibility:
• 3.5″ Bays: 3.5″ SATA hard drives
• 3.5″ Bays: 2.5″ SATA solid-state drives
• 3.5″ Bays: 2.5″ SATA solid-state drives
• 2.5″ Bays: 2.5″ SATA solid-state drives
• M.2 Slot: 2 x M.2 2280 PCIe Gen 3 x4 slots
• Hot-swappable
• SSD Cache Acceleration Support
• SR-IOV
• File System
• Internal Drives: EXT4
• External Drives: EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT (optional for ARM model)
• Supported RAID Types
• 8-bay (and more): JBOD, Single, RAID 0, 1, 5, 6, 10, 50, 60
• 6-bay: JBOD, Single, RAID 0, 1, 5, 6, 10, 50
• 4-bay: JBOD, Single, RAID 0, 1, 5, 6, 10
• 2-bay: JBOD, Single, RAID 0, 1
• Storage Management
• Maximum Individual Volume Size: 250 TB
• Maximum Number of Internal Volumes: 128
• Maximum Size of Shared Folders: 250 TB
• Maximum Number of Shared Folders: 512
• Connections – 2 x 2.5 GbE (2.5G/1G/100M/10M)
• 1 x 10GBASE-T
• Features – Wake-on-LAN (WOL) Only on port 2.5GbE
• Jumbo Frame
• Physical
• LED Indicators: Power/Status, LAN, USB, HDD1-6, SSD 1-2, M.2 SSD 1-2
• Buttons: Power, Reset, One-touch USB Copy
• Operating Temperature: 0 – 40 °C
• Storage Temperature: -20 – 70 °C
• Relative Humidity: 5 ~ 95 % relative humidity, non-condensing, wet bulb: 27 ºC
• Power Supply Unit: 250W PSU, 100-240 V
• Power Consumption: Operating Mode, Typical: 86.96 W
• Fan:
• System Fan: 2 x 80 mm, 12 V DC
• CPU Fan: 1 x 90 mm, 12 V DC
• System Warning: Buzzer
• Kensington Security Slot
• Max. Number of Simultaneous Connections (CIFS): with max memory: 2500
• Dimensions and Weight
• 225 × 292.9 × 319.8 mm
• 10.04 kg
• Review Date 26-01-2024 by RTY
