MSI Placa Base MAG B850 TOMAHAWK WIFI DDR5 ATX
202,94 €
Motherboard with integrated Wi-Fi and DDR5 support, perfect for gamers and enthusiasts.
Shipping Cost & Delivery Time
The MSI MAG B850 TOMAHAWK WIFI DDR5 ATX motherboard is a robust solution for those seeking performance and connectivity. With support for the new DDR5 memory, this motherboard ensures superior speeds and energy efficiency, making it ideal for gaming and demanding tasks.nnAdditionally, the integrated Wi-Fi allows for fast and stable Internet connectivity, eliminating the need for external adapters. The ATX design offers various expansion options, making it perfect for custom builds and future upgrades. Experience the best of AMD AM5 technology with the MSI MAG B850 TOMAHAWK.
Specifications
| Brand | msi |
| Model | 911-7E53-001 |
| Platform | – ATX ( 243.84 mm x 304.8 mm) |
| Chipset | – AMD B850 |
|
CPU
Supported
|
– Compatible with AMD Ryzen 9000/8000/7000 series desktop processors – Socket AM5 |
| Memory | – 4 x DDR5, maximum memory capacity: 256 GB – Compatibility with DDR5 memory 7600+(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz – Max. Overclocking frequency: 1DPC 1R Maximum speed of up to 7600+ MHz 1DPC 2R Maximum speed of up to 6400+ MHz 2DPC 1R Maximum speed of up to 6400+ MHz 2DPC 2R Maximum speed of up to 5400+ MHz – Compatible with dual channel mode – Compatible with unbuffered and non-ECC memory – Compatible with AMD EXPO |
|
Expansion Slots
|
– 2 x PCI-E x16 slot (Qty) Supports x16/x2 (For Ryzen 9000/ 7000 Series processors) Supports x8/x2 (For Ryzen 8700/ 8600/ 8400 Series processors) Supports x4/x2 (For Ryzen 8500/ 8300 Series processors) – 1 x PCI-E x1 slot (Qty) – PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) – PCI_E2 Gen PCIe 4.0 supports up to x2 (From Chipset) – PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Graphics | – 1 x HDMI Compatible with HDMI 2.1 with HDR and maximum resolution of 4K at 60 Hz – 1 x DisplayPort Compatible with DP 1.4 and maximum resolution of 8K at 60 Hz *Available only on processors with integrated graphics. Graphics specifications may vary depending on the installed CPU. |
|
I/O Ports,
Connectors
|
External
– 1 x DisplayPort 1.4 |
|
Other
Features
|
Storage
– 3 x M.2 (Quantity) – M.2_1 Source (from CPU): supports up to PCIe 4.0 x4 and 22110/2280 devices – M.2_2 Source (from CPU): supports up to PCIe 4.0 x4 and 2280/2260 devices – M.2_3 Source (from chipset): supports up to PCIe 4.0 x4 and 2280/2260 devices – 6 x SATA 6G (Quantity) * The M2_2 slot will not be available when using Ryzen 8500/8300 series processors ** M2_3 and PCI_E2 share bandwidth. M2_3 will operate at x2 speed and PCI_E2 will also when installing devices in both slots. LAN – Realtek RTL8125BG LAN 2.5 G Wireless LAN and Bluetooth – Wi-Fi 6E – The wireless module is pre-installed in the M.2 slot (Key-E) – Compatible with MU-MIMO TX/RX – Supports bandwidth of 20 MHz, 40 MHz, 80 MHz, and 160 MHz in the 2.4 GHz, 5 GHz, or 6 GHz bands – Compatible with 802.11 a/b/g/n/ac/ax. – Compatible with Bluetooth 5.3 * 6 GHz Wi-Fi 6E may depend on the regulations of each country and will be available on Windows 11. ** Bluetooth 5.3 will be available on Windows 10 build 21H1 and Windows 11. USB – 2 x USB 2.0 (rear) – 4 x USB 2.0 (front) – 4 x USB 5 Gbps Type A (rear) – 2 x USB 5 Gbps Type A (front) – 3 x USB 10 Gbps Type A (rear) – 1 x USB 10 Gbps Type C (front) – 1 x USB 20 Gbps Type C (rear) Network – Realtek RTL8125BG LAN 2.5Gbps LED Features – 4 x EZ Debug LEDs Audio – Realtek ALC4080 Codec – High-performance 7.1 channel audio – Compatible with S/PDIF output – Supports playback of up to 32 bits/384 kHz on the front panel Operating System – Compatibility with 64-bit Windows 11, 64-bit Windows 10 |
| Review Date | 27-11-2025 by RTY |
Additional information
| Weight | 1,0 kg |
|---|
