Name: Edimax Ceiling Access Point AX1800 Wi-Fi 6
Brand: Edimax
SKU: IRS01965
Availability: OutOfStock

The edimax access point Ax1800 Wi-Fi 6 is the perfect solution for those companies and homes that seek to improve their connectivity and network performance. Equipped with the latest Wi-Fi 6 technology, this access point offers speeds of up to 1800 Mbps, which allows the fluid video transmission in high definition, online games without interruptions and a stable connection for multiple devices simultaneously.nnDesigned to be installed on the ceiling, its elegant and discreet design is perfectly integrated into any environment, either in offices, restaurants, schools or commercial spaces. Thanks to its roof assembly, it optimizes the signal coverage, eliminating dead points and guaranteeing a robust connection throughout the area.nnEdimax Ax1800 not only stands out for its performance, but also for its ease of use. With a simple configuration, you can have your network in operation in a matter of minutes. In addition, it has advanced functions such as user management, bandwidth control and improved security options, ensuring that your network is protected and functioning efficiently.nnCompatible with previous devices, this access point ensures that all your connections, from smartphones to laptops, work without problems. Whether you need a reliable connection to work or to enjoy entertainment online, the edimax point access point Ax1800 Wi-Fi 6 is the ideal option to meet your modern connectivity needs. Do not wait any longer and transform your network experience with this powerful device.

Specifications

CAX1800
AX1800 Wi-Fi 6 PoE ceiling mount dual-band access point
– AX1800 high speed: maximum Wi-Fi speed of up to 1800Mbps (2.4GHz at 574Mbps and 5GHz at 1201Mbps).
– Efficient MU-MIMO: Serves multiple devices simultaneously for data transmission with improved capacity for wireless connections.
– High-performance Wi-Fi: Beamforming, AirTime Fairness, Band Steering, and 802.11r / k Fast Roaming enhance the best Wi-Fi performance.
– High-density mobile and IoT usage: supports up to 256 users simultaneously, ideal for BYOD workplaces.
– Secure and reliable Wi-Fi: WPA3 and WPA2-AES encryption is supported for a high level of security.
– Commercial environments: for offices, meeting rooms for schools, campuses, and hospitality businesses, such as hotels, restaurants, shopping malls, retail stores, and hospitals.

Brand	Edimax
Model	CAX1800
Features	Hardware – Interface: 1 x Ethernet RJ45 10/100 / 1000Mbps (PoE input) – Antenna: Type: 2 x built-in PIFA (2 dual-band antennas) Gain: 2.2dBi (2.4GHz), 2.9dBi (5GHz) Max. – Power: DC: 12V / 1A 802.3af (optional PoE injector) – Power consumption: 12W (full load) – Energy saving: 802.3az – Ceiling mount – Housing: UL94-5VB flammability rating – Dimensions: 176.29 (D) x 32.75 (H) mm – Weight: 372g Wireless – Standard: 802.11 a / b / g / n / ac / ax Concurrent dual-band – Frequency band: Radio I: 802.11b / g / n / ax 2.412 ~ 2.484 (GHz) Radio II: 802.11a / n / ac / ax 5.15 ~ 5.25 (GHz), 5.25 ~ 5.35 (GHz), 5.470 ~ 5.725 (GHz) (The supported frequency band is restricted by local regulations). – Maximum data rate: 2.4GHz: 574Mbps, 5GHz: 1201Mbps – Operating channels: 2.4GHz: US / Canada 1-11; 2.412 ~ 2.462GHz Europe 1-13; 2.412 ~ 2.472GHz 5 GHz: depends on the country for the following ranges: US / Canada: Band 1: 36, 40, 44, 48; 5.180 ~ 5.240 (GHz) Band 4: 149, 153, 157, 161, 165; 5.745 ~ 5.825 (GHz) Europe: Band 1: 36, 40, 44, 48; 5.180 ~ 5.240 (GHz) – Maximum transmission power: 802.11b 17dBm @ 1Mbps, 17dBm @ 11Mbps 802.11g 17dBm @ 6Mbps, 15dBm @ 54Mbps 802.11n (2.4G) 17dBm @ MCS0 (HT20), 15dBm @ MCS7 (HT20), 12dBm @ MCS9 (HT40) 802.11ax (2.4G) 9dBm @ MCS11 (HT40), 15dBm @ MCS4 / 12, 15dBm @ MCS5 / 13 14dBm @ MCS6 / 14, 14dBm @ MCS7 / 15 802.11a 17dBm @ 6Mbps, 16dBm @ 54Mbps 802.11n (5G) 17dBm @ MCS0 (HT20), 15dBm @ MCS7 (HT20) 802.11ac 17dBm @ MCS0 (VHT80), 15dBm @ MCS7 (VHT80), 14dBm @ MCS9 (VHT80) 802.11ax (5G) 10dBm @ MCS11 (HT80) (CE: 20dBm or less, FCC: 23dBm or less) – Receiver sensitivity: 802.11b: ≤-88dBm @ 1Mbps, ≤-86dBm @ 11Mbps 802.11g: ≤-88dBm @ 6Mbps, ≤-71dBm @ 54Mbps 802.11gn (2.4G): ≤-88dBm @ MCS0, ≤-68dBm @ MCS7, ≤-60dBm @ MCS9 802.11ax (2.4G): ≤-53dBm @ MCS11 802.11a: ≤-87dBm @ 6Mbps, ≤-68dBm @ 54Mbps 802.11n (5G): ≤-87dBm @ MCS0, ≤-68dBm @ MCS7 802.11ac: ≤ -56dBm @ MCS9 802.11a (5G): ≤ -50dBm @ MCS11 – Concurrent clients up to 100 per radio: No. of SSID 16 (2.4GHz) + 16 (5GHz) – 802.11 r / k Fast roaming – Band steering – AirTime Fairness – Beamforming Software – Wireless mode AP / WDS AP / WDS Bridge – 802.1q VLAN Y (VID = 1-4095) – Spanning Tree STP – QoS WMM (802.11e) Max number of associated stations – IPv6 and VPN (PPTP, L2TP / IPsec) pass-through – DSCP (802.1p) Y – Multicast speed of up to 54 Mbps Y Security – WEP / WPA2-AES / WPA3 encryption – L2 wireless isolation – Station isolation – IEEE 802.1x authenticator – EAP PEAP authentication – Hidden SSID – MAC address filtering – Wireless STA – Rogue AP detection (w / NMS) Management – Standalone deployment (AP mode) – Master AP mode: can manage 16 Edimax CAX1800 APs with NMS – Managed AP mode: to be managed by the Edimax CAX1800 master AP with NMS – HTTP / HTTPS configuration – SNMP v1, v2c, v3 – CLI (Telnet, SSH) – Built-in RADIUS server – Automatic channel – Private MIB Others – CE, FCC certification – Environmental condition: Operating temperature: 0 ° C ~ 40 ° C Operating humidity: 90% or less Contents – AX1800 PoE ceiling mount access point – Ceiling mount and T-rail support kit – Ethernet cable – Quick Installation Guide
Review date	18-06-2020 by MSB
