ASUS Motherboard PRIME H610M-E CSM D4

The ASUS Prime H610M-E CSM D4 motherboard is the perfect choice for those seeking solid performance and exceptional reliability in their computer systems. Designed to withstand the latest Intel processors of 12th generation, this Motherboard offers an excellent platform to build a powerful PC, either for daily tasks, gaming or more demanding jobs.

With a micro ATX format, Prime H610M-E CSM D4 is easily integrated into most computer boxes, optimizing the space without sacrificing functionality. Its intelligent design includes multiple DIMM slots that allow the installation of up to 64 GB of DDR4 memory, guaranteeing a fluid performance in multitasking and demanding applications. In addition, it has an M.2 interface and SATA ports that facilitate the connection of rapid and efficient storage units.

Asus’s advanced cooling technology ensures that the components work at optimal temperatures, prolonging the life of the system. With features such as survival protection and a robust design, this motherboard is ideal for users seeking durability and stability.

Prime H610M-E CSM D4 also includes a set of connectivity options, such as USB 3.2, HDMI and Ethernet ports, which guarantees that you can connect all your devices without problems. In addition, its compatibility with Asus Aura Sync allows customizing the RGB lighting of your team, giving it a unique and stylized touch.

In summary, the Asus Prime H610M-E CSM D4 is a motherboard that combines performance, reliability and aesthetics, making it an outstanding option for any computer enthusiast.

Technical Specifications

• Brand Asus
• Model 90MB19N0-M1EAYC
• Platform – mATX ( 24.4 cm x 21.1 cm )
• Chipset – Intel H610
• CPU
• Supported – Intel Socket LGA1700 for 13th and 12th Gen Intel Core processors, Pentium Gold, and Celeron
• Supports Intel Turbo Boost 2.0 and Intel Turbo Boost Max 3.0 technology
• Memory – 2 x DIMM slots, max. 64 GB, DDR4 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133
• Non-ECC, unbuffered memory
• Dual-channel memory architecture
• Supports Intel Extreme Memory Profile (XMP)
• *The supported memory types, data transfer speeds (speed), and number of DRAM modules vary depending on the CPU and memory configuration. For more information, please refer to the CPU/memories support list on the Support tab of the product information site or visit https://www.asus.com/support/.
• Graphics – 1 x DisplayPort 1.4
• 1 x VGA
• 1 x HDMI 2.1
• *Graphics specifications may vary between CPU types. Please refer to www.intel.com for updates.
• Expansion Slots
• 13th and 12th Gen Intel Core processors*
• 1 x PCIe 4.0 x16 slot
• Intel H610 chipset
• 1 x PCIe 3.0 x1 slot
• Note: To ensure the compatibility of the installed device, please refer to https://www.asus.com/support/ for the list of compatible peripherals.
• I/O Ports,
• Connectors
• Internal I/O Connectors
• Related to fans and cooling
• 1 x 4-pin CPU fan header.
• 2 x 4-pin chassis fan headers
• Related to power
• 1 x 24-pin main power connector
• 1 x 8-pin +12V power connector
• Related to storage
• 2 x M.2 slots (Key M)
• 4 x SATA 6Gb/s ports
• USB
• 1 x USB 3.2 Gen 1 connector that supports 2 additional USB 3.2 Gen 1 ports
• 2 x USB 2.0 headers that support 4 additional USB 2.0 ports
• Various
• 1 x RGB header
• 1 x Clear CMOS header
• 1 x Front panel audio header (AAFP)
• 1 x COM port header
• 1 x S/PDIF output header
• 1 x Speaker header
• 1 x SPI TPM header (14-1 pin)
• 1 x System panel header (10-1 pin)
• Rear Panel I/O
• 2 x USB 3.2 Gen 1 ports (2 x Type-A)
• 2 x USB 2.0 ports (2 x Type-A)
• 1 x DisplayPort
• 1 x D-Sub port
• 1 x HDMI port
• 1 x Realtek 1Gb Ethernet port
• 3 x audio connectors
• 1 x PS/2 keyboard port (purple)
• 1 x PS/2 mouse port (green)
• Others
• Features
• Storage
• Total supports 2 M.2 slots and 4 SATA 6Gb/s ports
• Intel H610 chipset
• M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x2 mode)
• 4 x SATA 6Gb/s ports
• USB
• Rear USB (6 ports in total)
• 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C)
• 2 x USB 3.2 Gen 2 ports (2 x Type-A)
• 1 x USB 3.2 Gen 1 port (1 x Type-A)
• 2 x USB 2.0 ports (2 x Type-A)
• Front USB (7 ports in total)
• 1 x USB 3.2 Gen 1 connector (compatible with USB Type-C)
• 1 x USB 3.2 Gen 1 connector that supports 2 additional USB 3.2 Gen 1 ports
• 2 x USB 2.0 headers that support 4 additional USB 2.0 ports
• LAN
• 1 x Realtek 1Gb Ethernet
• Audio
• High-definition audio codec with Realtek 7.1 surround sound*
• Supports: jack detection, multi-streaming, front panel jack re-tasking
• Supports up to 24-bit/192 kHz playback
• Audio features
• Audio shielding
• Premium audio capacitors
• Dedicated audio PCB layers
• *Requires a chassis with an HD audio module in the front panel to support 7.1 surround sound output.
• Operating System
• Windows 11, Windows 10 64-bit, Windows 10 64-bit
• Revision Date 17-01-2024 by RTY
